Description17-19 Ford F250/F350 w/6.7 Powerstroke Aluminum Radiator
2017-2019 Ford F250 F350 Powerstroke 6.7L Diesel Truck Aluminum Performance Radiator. AT/MT Cars. These COLD-CASE radiators are Tig welded 100 percent aluminum and absolutely beautiful. Don't buy a 3 or 4 row aluminum radiator!
It doesn't cool as good as these oversize 2 row models. These radiators are original appearing and have the correct stamping. Once painted, you'd be hard pressed to find a difference over an original versus a COLD-CASE.
Details:
- 100 percent TIG welded
- All Aluminum
- Polished OE style tanks
- 16 fins per inch
- Corrugated fins that give more surface area and more thermal transfer
- Pressure tested
- For auto/maual trans
- Direct fitment for 17-19 Ford Powerstroke 6.7L
Radiator Specs:
- Core Height 25.5 Inch
- Core Width 38.3 Inch
- Overall Height 28.5 Inch
- Overall Width 42.3 Inch Lower Bolt Holes
- Overall Thickness 3 Inch
- Upper Hose 2 Inch
- Lower Hose 2.20 Inch
- Tubes (2) 1 Inch Tubes
Specifications:
Core Height: |
25.5 Inch |
Core Width: |
38.3 Inch |
Engine: |
Powerstroke |
Finish: |
Polished |
Material: |
Aluminum |
Overall Height: |
28.5 Inch |
Overall Width: |
42.3 Inch |
Part Type: |
Radiator |
Thickness: |
3.0 Inch |
Transmission Type: |
Manual|Automatic |
