Description66-77 Ford Bronco Aluminum Performance Radiator And 16 Inch Fan Kit
66-77 Ford Bronco Aluminum Performance Radiator And 16 Inch Fan Kit. These COLD-CASE radiators are Tig welded 100 percent aluminum and absolutely beautiful.
Don't buy a 3 or 4 row aluminum radiator! It doesn't cool as good as these oversize 2 row models. These radiators are original appearing and have the correct stamping. Once painted, you'd be hard pressed to find a difference over an original versus a COLD-CASE.
- 100 percent TIG welded
- Fan Diameter 16 Inch
- All Aluminum
- Polished OE style tanks
- (2) 1.25 inch Tubes
- 16 fins per inch
- Corrugated fins that give more surface area and more thermal transfer
- Pressure tested
- For auto/manual trans
- Direct fitment for 66-77 Bronco
- Old Part Number: RPE574AK
Radiator Specs
- Core Height 18.5 inch
- Core Width 19.2 inch
- Overall Height 20.2 inch
- Overall Width 24.75 inch
- Overall Thickness 6 inch
- Tubes (2) 1.25 inch Tubes
Specifications:
AMP DRAW: |
5.69 Avg |
Blade Material: |
Curved Nylon |
Core Height: |
18.5 Inch |
Core Width: |
19.2 Inch |
Fan Diameter: |
16 Inch |
Fan Quantity: |
1 |
Finish: |
Polished |
Material: |
Aluminum |
Max Fan CFM: |
2800 CFM |
Overall Height: |
20.2 Inch |
Overall Width: |
24.75 Inch |
Part Type: |
Radiator Kit |
Thickness: |
6.75 Inch |
Transmission Type: |
Manual|Automatic |
