Description91-96 Corvette w/Automatic Transmission, Aluminum Performance Radiator
1991-1996 Chevy Corvette C4 Aluminum Performance Radiator. AT/MT Cars. Without filler neck. See CR-CHV719A for model with filler neck. These COLDCASE radiators are Tig welded 100 percent aluminum and absolutely beautiful. Don't buy a 3 or 4 row aluminum radiator!
It doesn't cool as good as these oversize 2 row models. These radiators are original appearing and have the correct stamping. Once painted, you'd be hard pressed to find a difference over an original versus a COLDCASE.
Details:
- 100 percent TIG welded
- All Aluminum
- Polished OE style tanks
- 16 fins per inch
- Corrugated fins that give more surface area and more thermal transfer
- Pressure tested
- For auto/maual trans
- Direct fitment for 8490 Corvette
Radiator Specs
- Core Height 16.85 inch
- Core Width 23.60 inch
- Overall Height inch
- Overall Width inch
- Overall Thickness 2.5 inch
- Tubes (2) 1 inch Tubes
- Upper Hose 1.35 inch
- Lower Hose 1.55 inch
Specifications:
Core Height: |
16.85 Inch |
Core Width: |
23.60 Inch |
Material: |
Aluminum |
Overall Height: |
18.75 Inch |
Overall Width: |
30 Inch |
Part Type: |
Radiator |
Thickness: |
3.0 Inch |
Transmission Type: |
Manual|Automatic |
