DescriptionCarb/EFI adjustable billet by-pass return style fuel pressure regulator 6AN Kit with Fuel Pressure Gauge and Adapter Fittings_x000D
These kits include a fuel pressure gauge and adapter fittings to get you started on your installation.
Features & Benefits
- Adjustable from 4-65 psi for precise fuel pressure adjustments
- Constructed of billet aluminum with a black anodized base and a clear anodized top for good looks
- Used in systems with a return line back to the tank
- (1) 6AN O-ring Inlet; (1) 6AN O-ring Outlet; and (1) 6AN O-ring return
- Includes fitting for manifold reference
- Includes an 1/8 NPT gauge port
- Boost Reference - 1:1
- The 4-15 psi carbureted spring comes installed in the regulator
Specifications:
| Grade Type: |
Performance |
| Inlet Type: |
6 AN ORB |
| Color: |
Black |
| Outlet Quantity: |
1 |
| Inlet Quantity: |
1 |
| Part Type: |
Fuel Pressure Regulator |
| Material: |
Aluminum |
| Return Size: |
6 AN O-Ring |
| Outlet Size: |
6 AN O-Ring |
| Product Type: |
Fuel Pressure Regulator |
| Fuel Type: |
Gasoline |
| Inlet Size: |
6 AN O-Ring |
| Mounting Hardware Included: |
Yes |
| Outlet Type: |
6 AN ORB |
| Style: |
Bypass |
Warranty:
Manufacturer's Limited 90 Day Warranty
