MSD Chevy V8 Pro-Billet Distributor for MSD 6/7/8-Series Ignition, Locked Out - (MSD-85501)

Description

Locked-out from the factory. Must be used with an MSD 6, 7 or 8-series ignition.

Trigger signals are produced via a high-output magnetic pick-up. This pickup is extremely accurate and never requires adjustment. Since this distributor is designed primarily for race engines, an oversized (+.006") bronze gear is installed along with an adjustable slip collar for modified blocks, heads or intake manifolds.

Features & Benefits

• Designed primarily for race applications with no mechanical advance
• Will not accept a vacuum advance canister
• Must be used with an MSD 6, 7, 8, or 10 Series Ignition
• Supplied with an HEI style distributor cap and rotor (accepts Cap-A-Dapts)
• Supplied with a 0.006” oversized bronze gear installed
• O-ring seals can be added to modified blocks to improve oil pressure control
• Special oil tract improves lubrication to the distributor and cam gear
• Polished steel shaft is QPQ coated and guided by a sealed ball bearing
• Adjustable slip collar mounting flange for engines with modified deck heights
• Maintenance-free magnetic pickup and precision reluctor create stable trigger signals throughout the rpm range
• CNC machined billet aluminum housing and billet aluminum base

Specifications:

Color:	Red
Product Type:	Distributor
Distributor Type:	Magnetic Pickup
Part Type:	Distributor

Warranty:

Manufacturer's Limited 365 Day Warranty
