MSD Pontiac V8 350-455 Pro-Billet Distributor - (MSD-8563)

Description

Fits 326, 350, 389, 400, 421, 428, and 455 Pontiac. Must be used with an MSD 6, 7 or 8-series ignition.

For stable timing, a high-output magnetic trigger pick-up is used to supply the ignition with a trigger signal. Additional stability is achieved via the 0.500" hardened distributor shaft that is supported by sealed ball bearings.

Features & Benefits

• CNC machined billet aluminum housing and billet aluminum base
• No CARB Exemption Order Number
• Will not accept a vacuum advance canister
• Must be used with an MSD Ignition Control
• Supplied with an HEI style distributor cap and rotor (accepts Cap-A-Dapts)
• Nylon pads ensure smooth operation of the advance weights
• Advance weight pins are staked and tig welded to the plate
• Mechanical advance assembly can be locked out for crank trigger systems
• Advance plate and weights are fine blanked from chrome moly steel and QPQ coated for friction reduction
• Polished steel shaft is QPQ coated and guided by a sealed ball bearing
• Maintenance-free magnetic pickup and precision reluctor create stable trigger signals throughout the rpm range
• Easy-to-adjust mechanical advance with supplied springs and stop bushings

Specifications:

Color:	Red
Product Type:	Distributor
Distributor Type:	Magnetic Pickup
Part Type:	Distributor

Warranty:

Manufacturer's Limited 365 Day Warranty
