DescriptionSwivel-Seal™ 30 Deg. AN Hose End; Fitting Size: -10AN Female; Hose End Size: -10AN; Anodized Red/Blue; Aluminum; Bagged Packaging;
Stainless retention pins allow 360 degree adjustment after installation. Dual plane anti-seepage seal. Precision machined. Bent tube design provides excellent fuel flow capacity. Nipple and cutter design assures leak free performance. Aerospace proven design and materials.
Features & Benefits
- 360 deg Adjustment After Installation
- Dual Plane Anti-Seepage Seal
- Precision Machined
- Excellent Fuel Flow Capacity
- Leak Free Performance
- Aerospace Proven Design & Materials
Specifications:
Adjustable Length: |
Yes |
Angle: |
30 Degree |
Compatible Hose End: |
Auto-Flex |
Finish: |
Anodized Red and Blue |
Fitting Size: |
-10AN |
Fitting Type: |
Swivel |
Hose Size: |
10AN |
Material: |
Aluminum |
Part Type: |
Clamp-On Hose Fitting |
Style: |
Crimp |
