DescriptionStealth Intake Manifold; Power Band Idle-6800 RPM; IMCA Legal; High Rise; Square Carb Mounting Flange; 4.37 in. Front H/5.06 in. Rear Height; No EGR Provisions; Satin Finish;
This manifold is part of the Weiand Nostalgia Series of intake manifolds. Weiand Nostalgia Series intake manifolds are made using the original tooling, and may have minor appearance imperfections that do not affect the functionality of the part. These minor blemishes are a natural part of the casting process when using the original sand casting tooling. Weiand Nostalgia series intakes are proudly cast and machined in the USA. We support all areas of the vintage, show, and nostalgia car hobby, and want to continue to produce these lower volume manifolds using the original tools. There is no need to search for that vintage intake at swap meets or on the internet when you can buy the real deal new from Weiand! *** Fits GT-40 and TFS heads.
Features & Benefits
- High Rise/Dual Plane Design
- Port Size 1.82 in. Height x 1.05 in. Width
- Height Front 4.37 in.; Rear 5.06 in.
- 1500-6800 RPM Power Band
- No EGR Provisions
- Square Carburetor Mounting Flange
Specifications:
Part Type: |
Engine Intake Manifold |
Barrel: |
Four |
Cylinder Head Type: |
Standard |
Emission: |
Without EGR |
Engine Make/Size: |
Ford Small Block V8 |
Front Height: |
4.370 in. |
Number Of Carbs: |
One |
Usage: |
Street/Strip |
Construction: |
Cast |
Finish: |
Satin |
Fuel System Type: |
Carb |
Manifold Type: |
High Rise |
Position: |
Lower |
Rear Height: |
5.060 in. |
RPM Range: |
1500-6800 |
