60-62 Chevy/GMC Truck C/K Series Aluminum Performance Radiator 26.5x25x3
1960-1962 Chevrolet Truck C/K Series Aluminum Performance Radiator. These COLD-CASE radiators are Tig welded 100 percent aluminum and absolutely beautiful. Don't buy a 3 or 4 row aluminum radiator! It doesn't cool as good as these oversize 2 row models.These radiators are original appearing and have the correct stamping. Once painted, you'd be hard pressed to find a difference over an original versus a COLD-CASE.
100 percent TIG welded
All Aluminum
2 Rows of 1.25 inch Tubes
16 fins per inch
Corrugated fins that give more surface area and more thermal transfer
Pressure tested
For automatic/manual transmission
OE style fittings
Direct fitment for 60-62 Chevy Truck
Radiator Specs:
Core Height 19 inch
Core Width 21.75 inch
Overall Height 25 inch
Overall Width 26.5 brackets inch
Overall Thickness 3 inch
Tubes (2) 1.25 inch Tubes
Upper Hose 1.57 inch
Lower Hose 1.8 inch
Specifications:
| Color: |
Silver |
| Core Width: |
21.75 Inch |
| Overall Width: |
26.5 Inch |
| Transmission Type: |
Automatic |
| Core Height: |
19 Inch |
| Finish: |
Polished |
| Overall Height: |
25 Inch |
| Part Type: |
Radiator |
| Thickness: |
3.0 Inch |
Warranty:
All Cold-Case radiators are guaranteed to be free from material and workmanship defects for the lifetime of the radiator.
