Description
77-87 Chevy/GMC Truck 19" Aluminum Radiator & Dual 14" Fan Kit 34.1x18.6x3
1977-1987 Chevy/GMC Pickup Truck 19 inch High Aluminum Performance Radiator and 14 inch dual fan kit. AT Cars. For taller 21 inch version, see CR-GMT556A21K.
When you need the biggest and best, look no further than the Cold Case Super Duty Line. All Super Duty kits include 2 row radiators with 1.25 inch tubes, aluminum fan shroud and dual 14 inch fans, flowing at 2200cfm per fan!
For extreme horsepower applications OR if you just want the best of the best. These COLD-CASE radiators are Tig welded 100 percent aluminum and absolutely beautiful.
Don't buy a 3 or 4 row aluminum radiator! It doesn't cool as good as these oversize 2 row models. These radiators are original appearing and have the correct stamping. Once painted, you'd be hard pressed to find a difference over an original versus a COLD-CASE.
100 percent TIG welded
Fan Diameter 12 Inch
All Aluminum
Polished OE style tanks
16 fins per inch
Corrugated fins that give more surface area and more thermal transfer
Pressure tested
For Automatic trans
Direct fitment for 77-87 GM Truck
Radiator Specs:
Core Height 17.2 inch
Core Width 28.35 inch
Overall Height 18.6 inch
Overall Width 34.15 inch
Overall Thickness 3 inch
Tubes (2) 1.25 inch Tubes
Trans Cooler Fitting: 5/16 inch Inverted Flare
Specifications:
AMP DRAW: |
6.85 Avg |
Fan Diameter: |
14 Inch |
Material: |
Aluminum |
Part Type: |
Radiator Kit |
Thickness: |
6.75 Inch |
Blade Material: |
Curved Nylon |
Max Fan CFM: |
3600 CFM |
Shroud Material: |
Yes |
